Nobel Chuck

Nobel Chuck


When it comes to chucks, a high degree of precision and safety is generally required.

The NOBEL-CHUCK chucks from KAWATATEC have been a guarantee for the implementation of very high market requirements since 1965 and meet these with the highest precision and process reliability. The NOBEL-CHUCKS are used on many lathes and especially in very large Versions as face plates on large vertical lathes.

Many satisfied customers in Japan and abroad rely on the high quality and safe technology from KAWATATEC

Nobel Chuck
Face plates with jaw boxes and/or clamping jaws

01

Face plates with jaw boxes and/or clamping jaws

4-jaw chuck face plates from the "44" series

  • Chuck body made of cast (GGG 60)

  • Chuck sizes D700-D1800mm

  • for direct mounting on type A spindle lugs

4-jaw chuck face plates with chip protection cover

IDV / IDK

  • Chuck body made of cast (GGG 60)

  • Chuck sizes D450-D1800mm

  • with chip protection cover

02

Manual chuck "TM"

3-/4-/6-jaw chucks of the “TM” series self-centering


For installation on a tombstone, on a machine tool table or on the table of a 5-axis machine

  • flat and light profile

  • with chip protection cover

  • Chuck size D400-D1200mm

TM manual power chuck for horizontal machining centers and 5-axis milling machines

03

CVH
Hydraulic Power Chuck

3-/6-Jaw CVH Power Chuck

Cast iron chuck body
Chuck size (D700 ~ D1600)
For adapter mounting (optional)
Jaw stroke: 30 mm (diameter)

3-Jaw CVH Power Chuck with Boring Mill Jaws

Chuck size (D700 ~ D1600)

For adapter mounting (optional)

Jaw stroke: 30 mm (diameter)

CVH power chuck hydraulic

04

Jaw BOXES of the series types BM-3T · BM-4T · BM-6T · BM-7T

for use on large lathes and large milling machines


05
On work

Boring mill jaws BM-3T, BM-4T, BM-6T, BM-7T
